Brushless DC BLW6121 Motor | 30W Quiet Motor for Home Appliances & Tools
Product Detail:
Zhengqiang brushless DC motors offer an economical, efficient and reliable solution for household appliances, fans, massage chairs, foam rollers, etc. Renowned for its simple design, easy control and stable performance, it ensures smooth operation and low maintenance. Suitable for household applications, this type of motor provides long-lasting power for various devices.
Specifications:
Input:110-120V,220V-240V,50/60 Hz
Output:24V
Speed:950 RPM
Control method:PWM Control
Rated Power:30W
Noise Level:≤45 dB(A)
Shaft:43.20±0.5mm/ custom
Weight:225g±3g
Direction of rotation:CCW
Bearing:Ball bearing
Zhengqiang brushless DC motors offer an economical, efficient and reliable solution for household appliances, fans, massage chairs, foam rollers, etc. Renowned for its simple design, easy control and stable performance, it ensures smooth operation and low maintenance. Suitable for household applications, this type of motor provides long-lasting power for various devices.
Specifications:
Input:110-120V,220V-240V,50/60 Hz
Output:24V
Speed:950 RPM
Control method:PWM Control
Rated Power:30W
Noise Level:≤45 dB(A)
Shaft:43.20±0.5mm/ custom
Weight:225g±3g
Direction of rotation:CCW
Bearing:Ball bearing
Products details
Brushless DC BLW6121 Motor Technical Specifications
Product Overview
Zhengqiang’s Brushless DC BLW6121 Motor provides:
-
Energy-efficient operation (30W rated power)
-
Ultra-quiet performance (≤45dB noise level)
-
Long service life with ball bearings
Product Drawing
Key Features
1. Precision Performance
Parameter | Specification |
---|---|
Speed | 950 RPM (±5%) |
Shaft Size | 43.20±0.5mm (customizable) |
Rotation | Counter-Clockwise (CCW) |
2. Advanced Control
-
PWM speed control for smooth operation
-
Compatible with 110-240V, 50/60Hz input
3. Robust Construction
-
225g lightweight design
-
Ball bearings for reduced maintenance
Applications
Home Appliances
-
Massage chairs & fascia guns
-
Ceiling fans & air purifiers
Power Tools
-
Electric wrenches
-
Vacuum cleaners (car/home)
Medical Devices
-
Blood pressure pumps
-
Deep water submersibles
